Product code: 120152

Size: 38cm Small, 43cm Medium, 48cm Large, 53cm X-Large

Find your nearest retailer


Curious about 29ers? The Xenon is the perfect first step into the epic world of singletrack and bush riding on a 29er. Confidence inspiring geometry allows you to develop into the sport with ease.

Product code: 120152


Size: 38cm Small, 43cm Medium, 48cm Large, 53cm X-Large


Did you know that for every bike we sell (including this one) we will plant a tree? Yes, that’s correct. By buying a Reid, not only will you be getting an awesome bike at a great price, you’ll be planting a tree in the process, sustaining the environments that we love to ride in! Well done you!



Built for true trail performance and designed in collaboration with elite cross country and trail riders, we bring you the Xenon – the most capable trail bike in it’s class.

A mix of trail optimised geometry and high spec components give an incredible ride for flowing singletrack and epic bush. With a whole host of top end features, the Xenon is trail ready.


Frame Double butted R2 alloy
Fork Suntour XCM-HLO 100mm travel with lockout and preload adjustment
Shifters Shimano Altus M2010 Rapidfire
Front derailleur Shimano Altus M2020
Rear derailleur Shimano M3000SGS
Freewheel / cassette Sugek 11-36T 9 Speed
Chainset Prowheel Zephyr 22/36 Double ring
Chain KMC X9
Bottom bracket Sealed bearing
Brakes Tektro HD-M275 hydraulic disc brakes
Brake Levers Tektro hydraulic
Wheelset rim WTB ST i25 disc rims
Hub Quando alloy quick release, disc specific
Tyres WTB Nineline 29 x 2.25″
Handlebars Reid oversize alloy
Stem Reid MTB 1-1/8″ threadless alloy, oversize
Grips Lock on MTB
Saddle WTB Volt Sport 142mm
Seatpost Reid alloy 27.2mm micro adjust
Pedals Platform

* We reserve the right to make changes to the product information contained on this site at any time without notice, including with respect to equipment, specifications, models, colours, and materials.


Main    Measurement    RC Length    Wheelbase    Front Center    BB Drop    Seat Tube Angle    Head Tube Angle    Seat Tube Length    Head Tube Length    Fork Rake/ Offset    Fork Length, Full    Top Tube Length
Measurement 38 cm 43 cm 48 cm 53 cm
Top Tube Length 590 605 615 625
Seat Tube Length 380 430 480 530
Head Tube Length 110 110 120 130
Seat Tube Angle 73 73 73 73
Head Tube Angle 69 69 69 69
RC Length 455 455 455 455
BB Drop 62 62 62 62
Fork Rake/ Offset 46 46 46 46
Front Centre 675 689 700 711
Wheelbase 1121 11437 1148 1159
Fork Length, Full 510 510 510 510

* Length measurements are in millimetres, unless otherwise stated.
